Features
CAT POWER
World-renowned for delivering dependable year-after-year performance, the four-cylinder CAT engine packs 1500cc of power for providing brute force strength to no matter how much - or whatever - territory you mow.
COMFORT IS KING FOR THIS CAT
Arguably the most comfortable, ergonomic and adjustable seat available anywhere is standard on our Diesel. With cushioned suspension, multi position controls for getting you just right for work, you might be so comfortable you'll find a new parking spot for it in your living room.
ONE COOL CAT
This is one cool CAT. Our larger radiator helps you keep your cool no matter how hot or how long - the days become. And with our larger hydraulic systems, our Diesel won't skip a beat in even the toughest conditions or warmest weather.
FUEL TANKS TO LAST ALL DAY
18 Gallon Fuel Tanks allow more mowing between fill-ups and features built -in control panel, fuel gauge and cup holders.
SWING-AWAY DESIGN ACCESS
This patented feature really is al it's cracked open to be. The ability to access virtually every serviceable component and make otherwise hard-to-reach places easy to clean, has been a hallmark of Bad Boy Mowers since our very first mower.
ARMORTEK5 MOWER DECK
With its unmatched strength and solid all-welded 3-gauge skirt on the leading edge. Next, we add an adjustable tapered front leading edge for adapting to any kind of grass or conditions. The deep 5.5" deck allows for greater volume of discharge and our inner baffles create more lift and vacuum for an exceptional cut. Lastly , our extended discharge promotes an even dispersal - the ArmorTek 5 simply blows all others away.
FOUR-RAIL ALL-WELDED STEEL FRAME
The core of every Bad Boy frame is a series of 11-gauge, 2"x2" steel cut and welded rails. Every innovation, every component and every feature of a Bad Boy rests on the reputation supported by this frame
EZ-RIDE SYSTEM
This patented system utilizes independent front and rear rubber compression shocks to absorb vibration from uneven terrain, allowing you to mow faster for longer periods with less fatigue. It also allows our fixed decks to glide more evenly over your mowing area for an even more manicured cut.
Specifications
| Mower Specifications | |
| Cutting Width | 6100 - 61"; 7200 - 72"; |
| Cutting Height | 1.5" - 5" with Deck Height Control System |
| Blades | 6100 - 1/4" x 2 1/2" x 21", High Lift, Heat Treated 7200 - 1/4" x 2 1/2" x 24", High Lift, Heat Treated |
| Lift and Height Adjustment | Instant Lift Electric Actuator |
| Blade Belt | Single V-Belt Spring Tension |
| Anti-Scalp Rollers | 6 Total (4 Front, 2 Rear) |
| Deck Flotation | Floats On 2 Chains & 2 Front Leveling Arms |
| Deck Thickness | 1/4" Thick Solid Steel |
| Engine Specifications | |
| Gross Horsepower/cc | 1500cc Caterpillar Diesel LC |
| Cylinders | 4 Diesel |
| Displacement | 1.5L/4-Cylinder |
| Maximum Torque | 94 ft. lbs. @ 3,000 RPM |
| Fuel Requirement | Diesel |
| Fuel Capacity | 18 Gallons |
| Fuel Filter | - |
| Cooling System | Liquid-Cooled |
| Ignition | Electronic |
| Starter | 12 Volt |
| Charging System | 20 Amp |
| Drive System Specifications | |
| Transmission | Dual Hydrostatic |
| Pump Drive | 16cc Hydro-Gear V-Belt From Engine Crankshaft |
| Wheel Drive | 18 cu. in. High Torque Parker Motors |
| Hydrostatic System Oil | 20W50 Motor Oil |
| Hydraulic Filter | 25 Micron, Replaceable Spin-On Type, 1 Per Pump |
| Pumps (2) | Hydro-Gear 16cc Pump |
| Hydraulic Coolers (2) | System Designed With 2 Coolers For Lower Temperatures |
| Mower Dimensions | |
| Weight | 6100 - 1,895 lbs.; 7200 - 1,935 lbs.; |
| Overall Height | 52" |
| Overall Width | 72 1/2" |
| Overall Length | 85" |
| Tire to Tire Width | 6100 - 57"; 7200 - 61"; |
| Tires - Front | 13 x 6.5 - 6 Smooth Tread |
| Tires - Rear | 26 x 12 - 12 Turf Tread |
| Steering | Dual Lever Steering, Independent Control |
| Turning Radius | Zero Turn - Zero Degrees, Turns Within Unit Length |
| Ground Speed (forward) | Up To 12 mph |
| Parking Brake | Disk Brakes |
