Features

  • Rotor Speeds of 185, 208, 235, or 266 RPM
  • 4-Speed Gearbox
  • CAT 4 Driveline
  • Slip-Clutch Protection
  • Gear Driven
  • Quick-Hitch Compatible

Specifications

Model SRM91V
Tilling Width 91"
Overall Width 96"
Tilling Depth (Max.) 8"
Support Stand Std
Hitch CAT 1-2, CAT 1 QH
Knife Type C
Number of Knives 54
Number of Flanges 9
Recommended PTO HP (Min/Max) 40 / 70
Rotor Speed (RPM) (at 540 RPM) 185/208/235/266 **
Driveline Size Cat 4
Driveline Protection Slip Clutch
Housing Thickness 4mm
End Plate Thickness 8mm
Rotor Drive Type Gear
Weight (Approx.) (lbs.) 992 Lbs.

** 4-Speed Gearbox
